SHIMANO FRONT CHAINWHEEL FC-M6100-1 DEORE FOR REAR 12-SPEED 2-PCS FC 175MM 30T W/O CG W/O BB PARTS FOR CHAIN LINE 52MM

SHIMANO DEORE - 2-PIECE CRANKSET - Chain Line 52 mm - 1x12-speed

Quantity: 1

DETAILED DESCRIPTION

The SHIMANO DEORE FC-M6100-1 crank features an entirely new construction, using direct mount chainrings, special gear tooth profile for improved chain retention, and a 172 mm Q-factor that is compatible with 142 mm or 148 mm O.L.D. frames.

FEATURES

  • Superior chain retention for smoother riding even over rough terrain
  • DYNAMIC CHAIN ENGAGEMENT+ improves chain engagement and retention
  • Direct mount chainring

SPECS

MODEL NO FC-M6100-1
SERIES DEORE M6100 Series
Color Series Color
2-PIECE CRANKSET
Chainring combination 30T
Compatible bottom bracket type_Outboard
Crank fixing screw included
Crank arm length (mm)_165 X (NEW)
Crank arm length (mm)_170
Crank arm length (mm)_175
Spider/Gear arms 4
Optional chain guard_Without chain/bash guard
Recommended bottom bracket_Press-fit BB-MT500-PA
Recommended bottom bracket_Threaded (normal) SM-BB52
Threaded bottom bracket shell width (mm)_68
Threaded bottom bracket shell width (mm)_73
Q-factor (mm) 172
Chain line (mm) 52
Compatible chain HG 12-speed
P.C.D. (mm) Direct
Rear speeds 12
O.L.D._QR/Nut (mm) 135, 141
O.L.D._Thru (mm) 142, 148
